防爆电动单梁起重机2 (1).webp

防爆电动单梁起重机1 (1).webp

Explosion-Proof Electric Single-Girder Crane

Model:

LB Explosion-proof Electric Single Girder Overhead Crane

Load Capacity:

1t, 2t, 3t, 5t, 10t, 16t, 20t

Span:

7.5m - 22.5m (Non-standard customization available)

Lifting Height:

6m, 9m, 12m, 18m, 24m, 30m

Duty Class:

A3, A4, A5

Power Supply:

3P AC 380V / 50Hz (Explosion-proof motor)

Ambient Temp:

25℃ to +40℃ (Explosion-proof area)

Control:

Explosion-proof pendant push button / wireless remote（dual control）

Get a Free Quote

Product Introduction

Explosion-proof beam cranes use explosion-proof electric hoists as their lifting mechanism and are lifting machines with explosion-proof characteristics. They can intermittently and repeatedly load, unload, and transport materials and equipment in explosive environments, and have vertical lifting, longitudinal, and lateral movement functions. The lifting device is a hook or other special lifting tool to meet the user's needs for lifting various types of materials.It mainly used in machinery manufacturing and places like assembling plants, storage houses.with the advantages of low energy consumption, strong rigidity, light weight, outstanding structural design, etc.

Explosion-proof beam cranes (hereinafter referred to as explosion-proof cranes) use explosion-proof electric hoists as the lifting mechanism and are lifting machinery with explosion-proof characteristics. They can load, unload and transport materials and equipment in explosive environments in an intermittent and repetitive manner, and have the functions of vertical lifting, longitudinal and lateral movement. The lifting device is a hook or other special lifting gear to meet the user's needs for lifting various types of materials.

Technical Data

Max. Lifting Height	Other	Warranty	1 Year
Machinery Test Report	Provided	Video outgoing-inspection	Provided
Rated Lifting Moment	Different	Place of Origin	Henan, China
After-sales Service Provided	Field installation, commissioning and training	Service	OEM

Application

Benefits & Features：
1. The structure is compact, lightweight, and imposes minimal load on the plant's load-bearing framework.
2. Simplify the structure to reduce manufacturing costs and achieve a more economical price.
3. Meet various explosion-proof requirements, including gas, dust, and MA (coal mining safety) standards.
4. Strong box type, one whole shape main beam welded by robot machine, very strong and beautiful.
5. Anti explosion function.

Full safety system as follows:
1.Weight overload protection
2.Emergency stop system
3.Over current protection
4.Short-circuit protection
5.Phase sequence protection
6.Zero position protection,Voltage loss protection Suitable for indoor dangerous working sites with flammable, explosive gas and dust. Widely used in petrochemical, chemical, pharmaceutical, coal washing, military and new energy industries. Adaptable for Zone 1 and Zone 2 explosive environments, working stably within the temperature range of -25℃ to +40℃.
