The New Type of Electric Hoist Semi-Gantry Crane is an advanced, space-saving lifting solution manufactured by Henan Mine, developed with lightweight, modular, and parametric design principles using a new type low-headroom electric hoist (NR mode) as the hoisting mechanism . This semi-gantry crane features one rigid leg running on a ground rail while the opposite side is suspended from an existing building overhead rail, making it ideal for workshops, warehouses, power stations, and other locations where a full bridge crane is not suitable or floor space is limited .

The crane offers lifting capacities from 1 to 20 tons, spans from 3 to 30 meters, lifting heights from 3 to 30 meters, working duty class A5, with full variable frequency speed regulation for stable operation and low-noise, energy-efficient performance . It supports multiple control options including ground pendant, wireless remote control, and cabin operation, with intelligent features such as inching movement for precise positioning, dead slow function, zero-speed hover to prevent slip hook, electronic anti-sway reducing load swing up to 95%, regional load limit, multi-hook coordination, and wireless expansion for full lifecycle management via industrial internet platform .

Core Applications – New Type of Electric Hoist Semi-Gantry Crane
1.Manufacturing Workshops – Handles raw materials, components, and finished products in mechanical processing, automotive assembly, and equipment manufacturing facilities where floor space is limited and bridge cranes cannot be installed .
2.Warehouses & Logistics Centers – Loads, unloads, stacks, and retrieves pallets, finished goods, and cargo in storage facilities, with space-saving semi-gantry design maximizing usable floor area.
3.Power Stations & Pumping Stations – Performs equipment maintenance, turbine servicing, and heavy component handling in power generation facilities where full gantry cranes cannot be accommodated .
4.Scrap Metal & Recycling Yards – Handles scrap metal loading, sorting, and unloading operations at scrap processing plants and recycling stations, with robust construction for harsh outdoor environments .
5.Ports & Outdoor Terminals – Transfers containers, steel coils, and general cargo from trucks and rail cars in port backup areas and freight terminals with rail-mounted configuration .
6.Construction & Precast Yards – Transports steel reinforcement, precast concrete components, and construction materials in open staging areas, with optional cantilever design extending reach beyond rail centers .
