The Downward Rotating Electromagnetic Hanging Beam Bridge Crane is a specialized overhead crane manufactured by Henan Mine, featuring an electromagnetic hanging beam mounted below the main beam with 360° horizontal rotation and telescopic adjustment, specifically designed for low headroom environments such as low-ceiling workshops, basements, and indoor factories with limited clearance. The crane is equipped with a powerful electromagnetic lifting system for handling ferrous materials including steel plates, coils, billets, pipes, profiles, and structural steel components, with telescopic beam allowing electric adjustment of magnet spacing and stepless control of magnetic force. The downward rotation configuration optimizes lifting height in space-constrained facilities, and typical specifications include lifting capacity from 5 to 50 tons, span from 10.5 to 53.3 meters, lifting height from 5 to 28 meters, duty class A5 to A7, beam rotation speed 0.8–1 r/min, and ambient temperature range from -25°C to +50°C.

The lower rotating clamp bridge crane is a special lifting equipment specifically designed for hoisting steel plates, sections, coils and other materials. Its core feature lies in the adoption of a lower rotating hanging beam structure with a rotating function, and it achieves efficient adsorption and handling through electromagnetic suction cups. It is used for fixed spans both indoors and outdoors in steel mills, ports, warehouses, etc., and can withstand high-temperature and high-dust environments.

It is used for fixed spans both indoors and outdoors in steel mills, ports, warehouses, etc., and can withstand high-temperature and high-dust environments.

Core Applications – Downward Rotating Electromagnetic Hanging Beam Bridge Crane
1.Steel Service Centers – Lifts and stacks steel plates, coils, and structural shapes in low-ceiling warehouses, with 360° beam rotation allowing turning of long materials and telescopic adjustment matching magnet spacing to plate length.

2.Low-Clearance Manufacturing Workshops – Handles heavy steel components in facilities with height restrictions, where standard cranes cannot achieve sufficient lifting height due to overhead obstructions or low roof trusses.

3.Shipyard Plate Processing Bays – Moves large steel plates and curved hull sections into position under welding robots or assembly fixtures, with rotating beam enabling multi-angle placement in confined fabrication bays.

4.Machine Shops with Overhead Cranes – Transfers steel billets, bars, and heavy tooling between machine tools in buildings with low roof trusses, where beam rotation allows precise alignment with worktables.

5.Coil & Pipe Storage Yards – Handles steel coils, pipes, and tubes in covered warehouses with limited vertical space, using telescopic beam to adjust for varying material lengths and rotating beam to change orientation during stacking.

6.Heavy Equipment Assembly Basements – Positions large steel components such as turbine casings, generator housings, and transformer tanks in underground or semi-basement assembly areas with severely restricted headroom.
