The Truss Gantry Crane is a lightweight, cost-effective rail-mounted lifting solution manufactured by Henan Mine, featuring a triangular truss structure welded from angle steel or I-beam that offers excellent wind resistance, light dead weight, and simple construction for outdoor material handling operations . This crane is used together with CD1, MD1, or other models of electric hoists, with the hoist traveling along the lower flange of the main beam's I-beam to complete lifting operations, and the gantry frame consisting of a main truss beam, legs, lower crossbeam, traveling mechanism, and electrical control system .

The truss structure provides significant advantages including strong wind resistance (wind pressure less than 125Pa), small windward side, easy installation and maintenance, and lower manufacturing cost compared to box-type gantry cranes . Typical specifications include lifting capacity from 3 to 32 tons (standard up to 20 tons), spans from 12 to 30 meters (customizable to 35 meters), lifting heights from 6 to 9 meters (customizable up to 12 meters), working temperature range from -20°C to +40°C, and working duty class A3 to A5 . The crane supports multiple control methods including ground pendant control, wireless remote control, and cabin control, and is forbidden to be used for lifting molten metal, flammable, explosive, or corrosive materials .

It is designed for lifting containers, steel materials, timber, precast concrete components, and general cargo in yards, logistics centers, warehouses, and construction sites. With flexible control options including pendant, remote, or cabin operation, and adaptable power supply such as cable reel or busbar, this crane offers reliable and cost-effective material handling. Typical specifications include lifting capacity from 3 to 20 tons, span from 12 to 30 meters, lifting height from 6 to 12 meters, duty class A3 to A5, power supply 380V/50Hz three-phase AC, and ambient temperature range of -20°C to +40°C.

Core Applications – Truss Gantry Crane
1.Outdoor Freight Yards & Warehouses – Loads, unloads, and stacks general cargo, steel coils, pipes, timber, and construction materials in open-air storage yards where wind conditions are a primary concern and cost-effective solutions are required .
2.Ports & Wharves – Transfers bulk materials and general cargo from vessels to trucks or storage areas, with lightweight truss design allowing easy relocation and optional cantilever extending reach beyond rail centers .
3.Construction Sites & Precast Yards – Transports steel reinforcement, precast concrete components, and construction materials in open staging areas, with simple structure enabling quick installation and minimal foundation requirements .
4.Mining & Metallurgy – Moves ore, coal, coke, and bulk materials in mining yards and steel plants, with truss design providing strong wind resistance for windy mountainous or coastal mining locations .
5.Bridge & Infrastructure Projects – Performs material handling for bridge construction, hydroelectric power stations, and large-scale infrastructure projects, with large span capability and excellent wind resistance for open-air worksites .
6.Warehouses & Logistics Centers – Handles pallets, finished goods, and raw materials in semi-covered or outdoor storage facilities where building structures cannot support overhead cranes and budget constraints favor truss over box-type designs .
